AEMC 5070 Megohmmeter
Category：
▶ AEMC
keyWord：
AEMC 5070 Megohmmeter
Describe:
AEMC 5070
Contact us
Description
http://www.jinstartech.com/
General Attributes:
AEMC 5070 very good price
Megohmmeter Model 5070 (Graphical, Analog Bargraph, Backlight, Alarm, Timer, 500V, 1000V, 2500V, 5000V, Ramp, Auto DAR/PI/DD, USB cable, w/DataView Software)
- True Megohmmeter with selectable test voltage from 40 to 5100V
- Insulation measurements from 30kO to 10TO
- Automatic step voltage with programmable step and dwell times - three profiles can be stored, each with up to five steps
- Programmable temperature compensation of resistance readings
- Automatic calculation of DAR, PI and DD values
- Direct measurement and display of Resistance, Test Voltage, Run Time, Capacitance and Leakage Current
- Automatic test inhibition if live voltage is present
- Automatic discharge and display of discharge voltage
- Large graphic display with five line alphanumeric display and graph of all test results
- Rugged weatherproof field case
Description
- True Megohmmeter with selectable test voltage from 40 to 5100V
- Automatic calculation of DAR, PI, and DD values
- Insulation measurements from 30kΩ to 10TΩ
- Rugged weatherproof field case
- Programmable temperature compensation of resistance readings
- RS-232 interface for direct printing of results
Megohmmeter (Graphical, Analog Bargraph, RS-232 w/DataView Software)
The Megohmmeter Model 5070 is a fully automated 5000V graphical insulation tester. Selectable and programmable test voltage (40 to 5100V). Programmable temperature correction of resistance readings. The Model 5070 is the only megohmmeter to offer both a graphical plot of the test right on the instruments, as well as a digital presentation of the test results. It has a large graphic display with a five-line alphanumeric display and graph. It also offers the ability to program up to three-step voltage profiles, each containing up to five steps. The Model 5070 has an RS-232 port that provides the ability to configure the unit and run the test from a PC. Test results can be generated directly to a printer using the DataView graphing and analysis software.
Manufacturer Specs
| AEMC 5070 Specifications | |
| Measurement Range | |
| Test Voltage/Range | 500V 30kΩ to 2000GΩ (2TW) / 1000V 100kΩ to 4000GΩ (4TW) / 2500V 100kΩ to 10,000GΩ (10TΩ) / 5000V 300kΩ to 10,000GΩ (10TW) |
| User Selectable Test Voltage | Programmable:40 to 1000V: 10V increments; 1000 to 5100V: 100V increments Programmable step voltage and duration in five steps. Three profiles can be stored. |
| Accuracy | 1kΩ to 40GΩ ±5% of Reading ± 3cts / 40GΩ to 10TΩ ±15% of Reading ± 10cts |
| Voltage Test/Safety Check | 0 to 1000V AC/DC (16 to 420Hz), 1V Resolution |
| Voltage Warning Indicator | Yes >25V |
| Test Inhibition | Yes >25V |
| Smooth Function (user selectable) | Digital filtering stabilizes display readings |
| GENERAL | |
| Storage of Readings over Time R(t) | 128kB memory |
| Report Print-out Direct to Printer | Preset format |
| Storage of Test Results | 128kB memory with RS-232 |
| PC Application Software | Yes (included) |
| Power Source | Eight NiMH rechargeable batteries 85 to 256V (50/60Hz) |
