General Attributes:

AEMC 6522 very good price

Megohmmeter Model 6522 (Digital w/Analog Bargraph, 250V, 500V, 1000V, Continuity, V)

• True Megohmmeter
• 1 kV Insulation and Continuity Tester
• 250V, 500V and 1000V Insulation Test Voltages
• 40GO Max Insulation Resistance
• Timed Test Mode up to 40 minutes for Insulation Resistance Test
• Test Lock feature for hands free timed measurements up to 15 minutes
• Continuity tests at 20mA or 200mA
• Test lead resistance compensation for accurate low resistance measurements
• True RMS AC/DC Voltmeter up to 700V
• Auto discharge after Insulation Test

Description

• True Megohmmeter
• 1 kV Insulation and Continuity Tester
• 250V, 500V and 1000V Insulation Test Voltages
• 40GΩ Max Insulation Resistance
• Timed Test Mode up to 40 minutes for Insulation Resistance Test

Megohmmeter (Digital w/ Analog Bargraph, 250V, 500V, 1000V, Continuity, V)

The Megohmmeter Model 6522 is a handheld, battery-powered 1000V digital insulation resistance tester. It is designed to measure Insulation Resistance, Continuity, and Voltage.

With a safety rating of 600V CAT IV and IP 54, the Model 6522 performs insulation resistance testing at 250, 500 and 1000V measuring values up to 40GΩ. It also incorporates a 700V AC & DC True RMS voltmeter and continuity testing with a selectable 20mA or 200mA test current.

The Model 6522 includes a Timer and Lock function which allows the user to operate the unit hands-free.

An automatic safety check protects the user and meter with audiovisual signals and test inhibition when >25V is present on a test sample. Large digital/analog multi-function display provides clear and easy readings enhanced by a bright blue electroluminescent backlight. Optional Remote Test Probe accessory with flashlight simplifies repetitive testing and helps access hard-to-reach, poorly lit, test areas. The Model 6522 is a great tool for basic insulation testing up to 1000V.

Applications

• Insulation measurement on communication cables, Ethernet cables, and other low voltage AC and DC wiring
• Insulation measurement on electronic components and circuits
• Special applications in the aerospace and defense sectors where specified test voltages are required
• Cables, small motors, pumps, transformers, and industrial equipment
