General Attributes:

AE Techron 7796HC very good price

Up to 200 Ap Inrush Current, DC to 100+ kHz, Three-Phase

• Stable when driving a wide range of resistive, inductive or capacitive loads
• Field-selectable controlled-voltage or controlled-current operation
• Can be switched between rail supply modes to optimize for various load impedances
• Protection circuits guard against over/under voltage, over current, over temperature, and circulating ground currents

Key Performance Capabilities:

• Up to 85A continuous at 13.5V DC; 70A at 28V DC
• Up to 200A in-rush current capability
• Stable when driving highly capacitive loads
• ±80V DC capable
• >35 V/µs slew rate
• Four-quadrant operation (source and sink)
• 208 VAC version ONLY; 400 VAC version not available

OVERVIEW

The 7796HC power amplifier offers up to 85 Ap continuous at 13.5 VDC, DC – 250 kHz small-signal bandwidth, and controlled-current or controlled-voltage modes of operation. The 7796HC can be used to simulate ripple noise, drop outs, surges and ground shift noise as required by a variety of standards for DC-powered electronics in the aviation and automotive industries.

A single 7796HC makes a very good choice for 13.5V DC-based power susceptibility test standards for high-current-draw EUTs (up to 85A).With configurations capable of up to 600Ap and the ability to both source and sink, the 7796HC is your best solution for high-current DC Conducted Immunity testing.
