General Attributes:

AE Techron 7794 very good price

Up to 200 Ap/100 Vp, DC to 150 kHz, Three-Phase

• Stable when driving a wide range of resistive, inductive or capacitive loads
• Field-selectable controlled-voltage or controlled-current operation
• Can be switched between rail supply modes to optimize for various load impedances
• Protection circuits guard against over/under voltage, over current, over temperature, and circulating ground currents

Key Performance Capabilities:

• 60A continuous at 13.8V DC
• 200A in-rush current capability
• 150 kHz small signal bandwidth
• ±95V DC capable
• >35 V/µs slew rate
• Four-quadrant operation (source and sink)

OVERVIEW

The 7794 is a powerful four-quadrant amplifier that offers up to 200 Ap power, DC – 100 kHz bandwidth, and controlled-current or controlled-voltage modes of operation. The 7794 works best into loads of 0.5 ohms or less. For greater voltage or current (up to 800 Ap) units can be combined in parallel or series.

Typically used when large currents are needed to drive very low impedances for long periods of time. Often used as a battery substitute for transient immunity testing requiring a battery as specified in EMC Test Standards for military, aviation and the automotive industries.
