AEMC 6240 10A Micro-Ohmmeter with Kelvin Clips and Probes
Category：
▶ AEMC
keyWord：
AEMC 6240 10A Micro-Ohmmeter with Kelvin Clips and Probes
Describe:
AEMC 6240
Contact us
Description
http://www.jinstartech.com/
General Attributes:
AEMC 6240 very good price
Micro-Ohmmeter Model 6240 (10A, Instantaneous, Continuous, Multiple Test, includes 10A Kelvin Clips (Hippo-Cat #1017.84), 1A Kelvin Probes Spring Loaded (Cat #2118.73), and DataView Software)
- 10A micro-ohmmeter
- This version includes kelvin clips / probes
- Catalog number 2129.80
- Reliable low resistance measurements
- Four-terminal Kelvin resistance measurement eliminates test lead resistance
- Measures up to 4000µO with 10A of test current
- 0.25% basic accuracy
- 1µO resolution
- Direct reading, easy to operate
- Test current selection of 1mA, 10mA, 100mA, 1A and 10A
Description
- Accuracy: ±(0.25%R + 2ct)
- Open Voltage: 4 to 6V
- Inductance: 0.5 H Max
- Storage Memory: 99 tests, supplied with DataView® software for download and reporting
- Operating Temperature: -10° to +55°C (14° to 131°F) & 10 to 85% RH
10A Micro-Ohmmeter with Kelvin Clips and Probes (Catalog # 2129.80)
The 10A Micro-Ohmmeter Model 6240 is a rugged, low resistance tester designed for both plant maintenance and field use. Utilizing a four-lead Kelvin method of testing, it accurately measures very low resistance within 0.25%.
Resistance measurements are automatically calculated from 1µΩ to 400Ω with resolutions down to 1µΩ. The Model 6240 has selectable test currents of 10A, 1A, 100mA, and 10mA and includes a polarity reversal function. It is designed to conduct tests on both resistive and inductive material and up to 99 measurements can be stored and printed directly to a printer or from a PC.
DataView (included) allows you to configure the instrument, temperature-compensate the test results, store data, and print reports.
The 6240 is packaged in a sealed field case well suited for shop and field use. Power is supplied by a long-life NiMH battery pack with a built-in recharger (110/220V). The large, easy-to-read liquid crystal display is 2.25 x 4.00". It displays the value of resistance, current or voltage test, polarity, and battery charge.
For operator safety and instrument protection, the micro-ohmmeter is fuse protected at the inputs. One fuse, accessible from the front panel, protects against stored energy in inductive loads. Enhanced internal circuitry protects against possible inductive kickback when the current is shut off. A built-in thermal switch protects the micro-ohmmeter against overheating on the 10A range when in continuous use.
Applications
- Bonding verification on earth/ground systems
- Weld joint integrity verification
- Contact resistance measurement of breakers and switchgear
- Aircraft and rail bonding checks
Manufacturer Specs
| AEMC 6240 Specifications | ||||||
| Specifications are given for an ambient temperature of 23°C ± 3°C, relative humidity of 45 to 55%, supply voltage of 6V ± 0.2V, and magnetic field of <40A/m. | ||||||
| Resistance | ||||||
| Measurement Range | 5.0 to 3999µΩ | 4.0 to 39.99mΩ | 40.0 to 399.9mΩ | 400 to 3999mΩ | 4.0 to 39.99Ω | 40.0 to 399.9Ω |
| Resolution | 1µΩ | 10µΩ | 100µΩ | 1mΩ | 10mΩ | 100mΩ |
| Accuracy | ± 0.25% ± 2ct | |||||
| Measurement current | 10.2A ± 2% (1) | 1.02A ± 2% | 102mA ± 2% | 102mA ± 2% | 10.2mA ± 2% (2) | |
| Open voltage | 4 to 6V | |||||
| Inductance | 0.5H Max | |||||
| (1) With a nominal value of 10.2A, the measurement current is at least 10A whatever the charge condition of the battery. (2) The current is 10mA only up to 300Ω. If the battery is low, it can fall to as low as 8mA. |
||||||
| Voltage Measurement Indication | ||||||
| Measurement Range | 0.01 to 3.999mV | 4.0 to 39.99mV | 40.0 to 399.9mV | 0.40 to 3.999V | 4.0 to 4.70V | |
| Resolution | 1µV | 10µV | 100µV | 1mV | 10mV | |
| Current Measurement Indication | ||||||
| Measurement Range | 5.0 to 39.99mA | 40.0 to 399.9mA | 0.40 to 3.999A | 4.0 to 11.00A | ||
| Resolution | 10µA | 100µA | 1mA | 10mA | ||
| Influences on the Resistance Measurement | |||
| Quantities of Influence | Range of use | Variation of the measurement | |
| Typical | Maximum | ||
| Temperature | -10 to +55°C | 0.1% /10°C | 0.5% /10 °C + 2cts |
| Relative Humidity | 10 to 85% RH @ 45°C | 0.1 % | 0.5% + 2cts |
| Supply Voltage | 5 to 7V | 2cts | 0.2% / V + 2cts |
| Series Mode Rejection, 50/60Hz* | U (AC) = (R measured x I measurement) | < 0.2% | 2% + 1ct |
| Common Mode Rejection, 50/60Hz AC | 0 to 50 V AC | > 80 dB | > 60 dB |
| *Example: If the measured resistance is 1mΩ and the measurement current is 10A, an alternating voltage of 1mV RMS in series with the resistance to be measured will induce an error of not more than 2%. | |||
| Power Supply: | 6V, 8.5Ah rechargeable NiMH battery pack |
| Battery Life: | Range dependent |
| Range | Number of measurements* |
| 10A | 850 |
| 1A | 3500 |
| 100mA | 4500 |
| 10mA | 5000 |
| In Standby or Off | battery life 4 to 6 months |
| *Established for measurements lasting 5s, every 25s | |
| Mechanical | |
| Dimensions: | 10.70 x 9.76 x 7.17" (272 x 248 x 182mm) |
| Weight: | 10 lbs (4.5kg approx) |
| Case Protection: | ABS plastic polycarbonate: watertight to IP64 (cover closed), water-resistant to IP53 (cover open). |
| Color: | Safety yellow case with gray faceplate |
| Environmental | |
| Operating Temperature: | 14° to 132°F (-10° to 55°C), 10 to 85% RH |
| Storage Temperature: | -40° to 158°F (-40° to 70°C); 10 to 90% RH |
| Altitude: | <2000m |
| Safety | Electrical safety as per EN 61010, EN 61557. |
| Degree of pollution: | 2 |
| Protection: | Measurement CAT III, 50V with respect to earth, 500V differential between terminals, and 300V CAT II on the charger input |
| Electromagnetic Compatibility: | The instrument satisfies the CEM and DBT directives required for the CE marking and product standard EN 61326-1 Emissions in a residential environment Immunity in an industrial environment |
Tech Specs
Micro / Milli / Meg Ohmmeters/Micro-Ohmmeter / DLRO / Bond Testing Template |
|
|---|---|
| Style (Micro-Ohmmeter) | Portable |
| Maximum Test Current | 10 A |
| Variable Test Current | Yes |
| Min Resistance | 4 u Ohms (0.004 m Ohms) |
| Max Resistance (ohm) | 400 Ohms |
| Alarm | No |
| Temperature Compensation | Yes |
| Line Power or Battery power | Battery Power, Line Power |
| Kelvin Four-Terminal Measurement | Yes |
Test Equipment General Attributes |
|
| Unique Features | Direct printout of measurement results using DataView software and a PC |
| Warranty | 1 YEARS |
| Warranty Details | http://www.aemc.com/warranty.html |
| Safety Approval | CE |
| Interfaces I/O | USB |
| Storage | Internal Memory |
| IP Rating | IP54 |
| Product Weight | 10 LBS |
| Product Height | 7.17 IN |
| Product Length | 9.76 IN |
| Product Width | 10.7 IN |
| Data Logging | Yes |
| Calibration Included | Factory Calibration |
| Battery Type | NimH |
| Power Supply Voltage | 120V/220V Universal, Battery Powered |
| Country of Origin | France |
