General Attributes:

Trend Networks UniPRO MGig1  very good price

• Ethernet transmission tester for carrier and enterprise networks
• Comprehensive in-line network monitoring
• Simplified set-up of target devices, services and tests
• RFC2544, BERT, SLA-Tick and Y.1564 (NetSAM)
• Simultaneous testing of multiple services
• QoS tests – multiple VLAN (QinQ), MPLS, ToS and DSCP

Product highlights

Designed for comprehensive turn-up testing, monitoring and troubleshooting of fixed line, mobile, microwave and wireless carrier Ethernet links.  UniPRO MGig1 is suitable for use on any backhaul link at speeds of up to 1 Gb/s.

UniPRO MGig1 allows enterprise users to monitor the actual bandwidth and performance compared to the agreed service levels from the service provider. It can also be used to stress test and monitor the performance of LAN backbone links.

Carrier users:

• Telco, cable TV, broadband, metro Ethernet WAN and leased line service providers
• Mobile network operators
• Data centers

Enterprise users:

• Managers of public utility, industrial, transportation, health care, education and financial networks
• LAN installation and maintenance personnel
• System integrators

Key features

Reduce configuration time with independent set-up parameters (devices, services and tests)

Unlike a typical Ethernet transmission tester, where the configuration of target devices, services and type of tests are mixed together, the UniPRO MGig1 separates them into 3 easy to manage independent processes.

One touch to run multiple tests – unattended Single button Autotest is an automatic sequence test function that executes user defined multi test items for specific applications (such as radio link installation)The most cost-effective RFC2544/Y.1564 tester in the market

UniPRO MGig1 performs Bi-Directional or loop back testing of Y.1564 and RFC2544 including  a jitter sub test with an-easy to understand pass/fail curve.

Bi-Directional CIR (committed information rate), EIR (excess information rate) and policing tests with color identification makes the Ethernet link test a better real-world simulation of multi-stream network traffic compared to RFC2544.
