REULAND Multi-Speed Motors 2-SPEED DUAL WIND MOTORS

Category：

▶ REULAND

keyWord：

Describe:

2-SPEED DUAL WIND MOTORS

Description

http://www.jinstartech.com/

General Attributes:

REULAND 2-SPEED DUAL WIND MOTORS very good price

2-SPEED DUAL WIND MOTORS

2-speed dual wind motors are most commonly used in applications where the speed ratio between high speed and low speed is anything other than 2:1. For continuous duty, 2-speed dual wind motors are usually offered in open drip proof or totally enclosed fan cooled enclosures with NEMA B electrical design. The customer has the option of choosing between constant torque, variable torque, or constant horsepower designs. Intermittent duty 2-speed dual wind motors are generally totally enclosed non-ventilated enclosures designed for 15, 30, 60, or 120-minute duty and have NEMA D electrical design.

Design Type	AC induction; Nema design B and D; constant torque, constant horsepower and variable torque
Power	Up to 300 HP
Speed	Any two speed combinations of 3600, 1200, 900, 600, 450, 300 rpm; other custom speeds also available
Voltage	Up to 600 volts
Phase	3-Phase
Frequency	60 Hz
Stator	M-19, M-36, or M-45 electrical steel laminations. Other lamination grades are available upon request. Hand-wound to ensure balanced and symmetrical windings.
Rotor	M-19, M-36, or M-45 electrical steel laminations. Other lamination grades are available upon request. Die-cast aluminum, copper, or copper alloy rotor construction.

Frame	NEMA frames 56 through 449, U & T frame configurations; Custom frames are also available, consult factory.
Construction	Cast iron or cast aluminum frame and end bells. Consult factory for stainless steel construction and/or custom design
Enclosures	Fan-Cooled (TEFC); Auxiliary Fan Cooled (A-TEFC); Non-Ventilated (TENV); Open Drip Proof (ODP).
Bearings	Heavy-duty Steel ball, Ceramic ball, or Roller bearings to suit specific applications.
Bearing Lubrication	Pre-Lubricated Sealed or Shielded; Re-Greasable Open
Balance	Precision and/or NEMA Standard.
Insulation	Class B, F, H and VPI.
Mounting	Foot or Footless; Precision Bracket Mounting; Conventional C or D Flange; Metric DIN Flanges.
Accessories	Temperature Sensors, Brakes, Vibration Mounts and Sensors.
