General Attributes:

AEMC 6555 very good price

Megohmmeter Model 6555 (Graphical, Analog Bargraph, Backlight, Alarm, Timer, 500V, 1000V, 2500V, 5000V, 10kV, 15kV, Ramp, StepV, Variable, Auto DAR/PI/DD, USB, w/DataView Software)

• Detection and measurement of input voltage, frequency, and current prior to running a test
• Measurements at a fixed test voltage of 500, 1000, 2500, 5000, 15,000VDC
• Ramp voltage measurements with a ramp from 40 to 1100V
• Step voltage measurements with steps from 40 to 15,000V
• Non-destructive (Early break) test, test stopped at a preset current (Break at I-limit) or Burn mode with no predefined stop point
• Digital filtering of insulation measurements
• Live measurement of the voltage to warn the operator of potential unsafe conditions
• Programmable thresholds to trigger audible
• Timed measurement duration checks
• Fuse protection with display indication of defective fuse condition

Description

• Live measurement of the voltage to warn the operator of potential unsafe conditions
• Programmable thresholds to trigger audible
• Timed measurement duration checks
• Detection and measurement of input voltage, frequency, and current prior to running a test
• Non-destructive (Early break) test, test stopped at a preset current (Break at I-limit) or Burn mode with no predefined stop point

Megohmmeter, 15kV (Graphical, Analog Bargraph)

The Megohmmeter Model 6555 is a high-end portable measuring instrument intended for the measurement of a wide variety of electrical insulation resistance values on cables and devices operating at high voltage. It is the only fully automated 15,000V graphical insulation tester. The True Megohmmeter® Model 6555 is packaged in a rugged case that is IP65 when closed. Test results and configuration information are displayed on a graphical LCD screen and are exportable via DataView® (provided). This megohmmeter can operate on battery or AC power.

The Model 6555 also offers the ability to program up to three step voltage profiles (from 40 to 15,000V), each containing up to ten steps. There are also three ramp profiles and three programmable test voltages in addition to the standard fixed voltages of 500, 1000, 2500, 5000, 10,000 and 15,000V.

Applications

• Acceptance testing and preventive maintenance
• Test motors, pumps, valves, cables, switchgear and electrical wiring installations
• Continuity checks
• High resistance or absorption tests
• Spot reading tests
• Timed resistance measurements
• Dielectric Absorption Ratio (DAR) and Polarization Index (PI) tests
• Multi-layer insulation testing (DD)
• Test old or water damaged installations over long time periods
• Motor insulation resistance measurements

Specifications
