General Attributes:

AE Techron 7224 very good price

900VA, single-phase, 2U, industrial amplifier/battery simulator

• Field-selectable controlled-voltage or controlled-current operation
• Can be switched between rail supply modes and voltages to optimize for various load impedances
• Protection circuits guard against over/under voltage, over current, over temperature, and circulating ground currents

Key Performance Capabilities:

• Up to 900 watts RMS power output
• Provides rated long-term power at frequencies up to 40 kHz
• Small signal response up to 1 MHz
• Up to 16A at 13.5 VDC
• Can be used to create series or parallel systems for up to 3 times the voltage or 4 times the current output

OVERVIEW

The 7224 is a 4-quadrant power amplifier that offers the features of larger industrial amplifiers in a smaller 2U size that runs from single phase 120/230VAC. It features DC – 400 kHz bandwidth, controlled-current or controlled-voltage modes of operation and has a wide range of field-configurable options.

The 7224’s configurability and flexibility have made it the choice of many research and university labs. It can be field-configured to run well into loads from 100 ohms to as low as 0.5 ohms. Even with its small bench top size, the 7224 is able to produce as much as 50 amps of current and as much as 158 volts, providing serious power for a wide range of applications and experiments. With its 90V/µS slew rate, it is able to accurately reproduce wave forms from DC to above 400 kHz, making it a great choice for high-speed control applications. With its ability to operate in either Controlled-Voltage or Controlled-Current modes, it has been used in Small Bore MRI and NMR systems, testing of switch-mode power supply components, and driving Helmholtz coils.

OUTPUT CHART
