Hirschmann Unmanaged Rack-Mount Switches very good price

Industrial applications need easy-to-install, scalable and reliable switching solutions to smoothly connect multiple workgroups. Belden’s Unmanaged Industrial Rack-Mount Ethernet Switches are rugged for hardened industrial applications. Suitable for telco and harsh industrial environments, the switches guarantee high network availability and environmental adaptability. Additional fiber ports provide uplink communication and isolation from other subnets.

Features & Benefits

• Plug-and-Play Operation: Automatic learning of addresses and adapting switching services to network changes
• Transform to IIoT: Devices provide simplified installation and maximized throughput

4K-Series Ethernet 10/100 Switches

Boosting the performance of Ethernet LANs with the flexibility of both twisted-pair and fiber-switched ports

Easy to install and use, the Magnum 4K-Series provides the switching speed and reliability needed to smoothly support multiple workgroups. All ports support full- and half-duplex as well as auto-negotiation on TP ports.

High performance non-blocking operation, plug-andplay installation for switching services, transparent to system software

Has a compact 1U package for installation in rack cabinets, with metal case and auto-ranging internal power supply

Easy to install and use with automatic address learning and choice of “forward” and “reverse” models for convenient mounting of ports, LEDs and power connections

Key Features

• 8-, 16- and 24-port options

• 48VDC, 125VDC and AC

• Dual-source

• NEBS and ESTI Certification

• 23 inch Telco brackets

• Class B EMI and extended temperature range operation

• Additional fiber ports with 100Mb speed and connector types for LC, ST, SC, and MTRJ

• Dynamic 2K-node address table

Magnum 4K-Series switches offer application flexibility with a series of optional fiber connector types. All applicable fiber port types (100 Mb FX-ST, SC, MTRJ) and fiber cable modes (multi- and single-mode) are configurable using a family of 1-or 2-port modules. The 1 or 2 fiber ports, when present, render the corresponding two copper ports inoperative.

Magnum 4K-Series switches are easy to install and use. Addresses of attached nodes are automatically learned and maintained, adapting the switching services to network changes and expansions to provide plug-and-play operation. “Reverse” models with front-mounted ports and LEDs, or with front-mounted LEDs, rear ports and power connection, are available.

Magnum 4K-Series switches provide high port density in a rack-mountable package; have a rugged metal case and an auto-ranging power supply for operation with standard AC power worldwide. Models with optional DC input power are available. The 4K-Series and all other Magnum products are designed and manufactured in the USA and backed by a three-year warranty.

Applications

These switches are designed for use in organizations with multiple workgroups, remote offices and network traffic centers. In common application, the Magnum 4K-Series would be at the center of a department LAN, which high performance users and servers connected. In addition, groups of 10Mb hubs and switches would form a series of subnets of other users. Local traffic on one subnet or port, either 100 Mb or 10Mb, is switch-isolated from the other subnets for high overall network performance.
