Features

• Includes NIST-Traceable Calibration Certificate
• The MVX is equipped with multiple viewing options to provide users with a complete set of inspection tools: (RF waveform, +/- Rectified waveform, Time based B-Scan, and Large Digits).
• The A-Scan rectified mode is commonly used for detecting flaws/pits in pulse-echo mode and measuring through paint and coatings in echo-echo mode.
• The time-based B-Scan feature of the MVX displays a cross section of the test material. It is commonly used to display the profile of the bottom surface of the test material.
• Built in hardware AGC gain control for through paint measurements in multi mode operation.
• The MVX has the ability to store 64 custom user defined setups. All factory setups can be selected, edited and saved to any setup location.
• Use the visual alarm to set hi and lo limits for applications requiring specific tolerances. If the actual thickness value is above or below the limits, a red light is illuminated.
• Use the find feature to locate the detection point, while automatically adjusting the display to bring the signal into view.
• MVX also comes complete with our Windows® PC software for transferring data to and from a PC.
• Includes Flaw Inspection - Prove Up Mode, (special probe required)
• The high speed scan feature speeds up the inspection process by making 32 measurements per second. Remove transducer from the tesst material, and display the minimum measurement scanned.
• IP 65 Rated
• CE Certified
• Warranty: Gauge: 2 Years Probes: 90 Days
• Made in USA
